Key Features
Output Rating:
Power:
1.5KVA, 3ø (61701);
3KVA, 3ø (61702);
4.5KVA, 3ø (61703);
6KVA, 3ø (61704);
12KVA, 3ø (61705)
Voltage: 0-150V/0-300V
Frequency: 15~1.2kHz
Phase angle: 0~360˚ Programmable
Built-in PFC, provides input power factor of over 0.98
AC+DC output mode
Comprehensive measurement capability,V, Irms, Ipk, Iinrush, P, PF, CF of current etc.
Programmable r.m.s. current limit
Turn on, turn off phase angle control
Full protection: OP, OC, OV and OT protection
Optional GPIB and RS-232 interface
Advanced PWM technology delivers high power density in a compact rack-mountable package
User-definable power-on status
Built-in output isolation relays
Easy use graphic user interface: softpanel (Option)
Optional function for transient voltage output, including LIST, PULSE, STEP ans INTERHARMONICS mode
